| Place of Origin: | China |
| Brand Name: | HKV |
| Certification: | CE, Ex, ATEX, IECEx, WF2 |
| Model Number: | NEW-FBP-80W |
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | Negotiated |
| Packaging Details: | 1pc/carton |
| Delivery Time: | 30 to 50days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 100000 per a month |
| Model Name: | NEW-FBP-80W | Input Voltage: | AV90-265C |
|---|---|---|---|
| Power Factor: | 0.96 | Power: | 80W |
| Lumen: | 110-130lm/W | CCT: | 2700-6500k |
| CRI: | 85 | Operating Temperature: | -35℃ To +40℃ |
| IP: | IP65 | Liifespan: | 50000h |
| High Light: | explosion proof light fittings,industrial explosion proof lighting |
||
NEW-FBP-80W Chian top 10 high power explosion proof led lamp IP67 waterproof
1. specification
| Model Name | NEW-FBP-80W |
| Input voltage | AC90-265V |
| Power frequency | 50/60Hz |
| Power factor | 0.96 |
| Watte | 80W |
| Lumen | 8800lm |
| Luminous Efficiency | 110-130lm/w |
| CCT | 2700-3500K 3500-5000K 5000-6500K |
| CRI | Ra>=85 |
| Operating Temperature | -30℃ to 45℃ |
| IP | IP67 |
| Anti-corrosion | WF2 |
| Lifespan | >50000h |
| Certification | EX, IECEx, ATEX, CE, WF2 |
2. Products Description
A) Body in die-casting copper-free aluminum alloy, treated by electrostatic spraying. with good performance of high temperature resistance
and climate resistance. Tempered glass with good transmittancy.
B) Driver: Isolation class I, protection OPP / OVP / SCP / OTP, Wide input voltage 90-265VAC, built-in active, THD<15%.
Surge Protection 10KV / 6KV / 4KV.
3. Installation show
Different Install according to the actural use.
4. Packing Information
N.W.: 11.2kg
Inner carton size: 30*30*27cm
Outer carton size: 62*31*29 (2pcs/ctn)
G.W.: 24kg/ctn
5. Suitable for different environments dangerous
1) Used in the olifiled, chemical industry, steel industry, power port, petroleum etc.
2) Harsh environment, moist area Zone1 Zone 2
3) Gas explosive environment: Group IIA, IIB, IIC. Temperature class: T5 to T6
6. Our service
1. Welcome OEM/ODM.
We can accept your own brand or design.
2. Quality control.
1) After the sample is confirmed, we will prepare the material production order in strict accordance with the sample, and test the goods in strict accordance with the sample quality.
2) Our salesman ,also as a order follower,would trace every phase of production from the beginning.
3) We have a QC team ,every product would be checked by them before packed.
4) We would try our best to help clients solve problems when they occurred.
3. Welcome to visit.
When you come to our company visIt us, we will arrange car for picking up and help you book hotel. If you want to visit the local scenic spot, our colleague will accompany you.
4. After-service
1) In production and after delivery, we will track on time and tell your goods situation.
2) When the goods arrived, if you find any design and quality question, or difference from your samples, please feel free to contact us, we will find the question and solve it with you.
