Place of Origin: | China |
Brand Name: | HKV |
Certification: | CE, UL844, ETL, DLC, CCC |
Model Number: | HKV-XT120 |
Minimum Order Quantity: | 100 |
---|---|
Price: | neogotiable |
Packaging Details: | brown carton or customized |
Delivery Time: | 15days to 50days |
Payment Terms: | L/C, D/A, D/P, T/T |
Supply Ability: | 10000pcs per a month |
Mold#: | HKV-XT120 | Power: | 120W |
---|---|---|---|
Led Source: | Brand Led SAMD | Input Voltage: | AC100-277V |
PF: | 0.98 | Driver: | MW |
Lumen Efferency: | 120lm/W | CCT: | 6000-6500K |
CRI: | >75 | Warranty: | 5 Years |
High Light: | explosion proof light fittings,industrial explosion proof lighting |
HKV-XT30/60W/60w high quality linear explosion proof light
1. Specification
mold# | HKV-XT120D | HKV-XT160A |
power | 120W | 160W |
led source | CreeBridgelux 144pcs | CreeBridgelux 144pcs |
Input voltage | AC100-277V | AC100-277V |
lumen | 120lm/W | 120lm/W |
Driver | MW | MW |
PF | 0.98 | 0.98 |
CCT | 2700-6500K | 2700-6500K |
CRI | >75 | >75 |
Beam angle | 120 degree | 120 degree |
Hazardos area |
CID1, CID2, CIID1, CIID2, CIII Zone1, Zone2 |
CID1, CID2, CIID1, CIID2, CIII Zone1, Zone2 |
temperature | -40℃ ~ +55℃ | -40℃ ~ +55℃ |
IP | IP67 | IP67 |
warranty | 5years | 5years |
dimension | 1192*126*57MM | 596*434*108MM |
Weight | 13KG | 9KG |
2. Advantages
A) cree or bridgelux led source. Insure the lifespan of the lamp and make it totally comply with UL844, ETL, DLC. also the cover for each chip make the lamp more brighter. Completed lamp luminous efficiency close to 120lm/W. Lonly led chips installation, the lamp keep working even 1 or 2 pcs chips break.
B) Aluminum body, easy for heat dissipation.
C) IP67 waterproof and stainless screws. better at waterproof, anti-dust, anti-rust, lamp lifespan more than 50000hours. Warranty 5 years, no worries about after service.
D) Brand driver meanwell, no flickers when lamp working.
3. Our service
We can accept your own brand or design.
1) After the sample is confirmed, we will prepare the material production order in strict accordance with the sample, and test the goods in strict accordance with the sample quality.
2) Our salesman ,also as a order follower,would trace every phase of production from the beginning.
3) We have a QC team ,every product would be checked by them before packed.
4) We would try our best to help clients solve problems when they occurred.
When you come to our company visIt us, we will arrange car for picking up and help you book hotel. If you want to visit the local scenic spot, our colleague will accompany you.
4.After-service
1) In production and after delivery, we will track on time and tell your goods situation.
2) When the goods arrived, if you find any design and quality question, or difference from your samples, please feel free to contact us, we will find the question and solve it with you.
5. Shipping
More options for shipping your cargoes:
A. By express: DHL,UPS,FEDEX,TNT,USPS etc. delivery time for 3-7 days.
B. Air freight: when your cargoes are more than 100kg, air freight will be more economical than express.
C. Sea freight: shipping by SEA is available after customer tells us the destination port.
D. Agent designated by client: please tell us the contact details of your shipping agent / forwarder.
6. The Feedback
Contact Person: Alicia Tang
Tel: +8618780041517
